A desirable design means less up-front investment and more late-stage revenues for a stone crusher plant, therefore, most customers pays attention to the design issue while investing a stone crusher plant. In this article, the manufacture offer ten tips for you to design a cost-effective and efficient stone production line based on own experience and customer feedback.

1. According to the on-site construction conditions, rationally distribute the production line to facilitate the working process of stone crusher plant; adopt compact structure to save space.

2. The equipment that requires heavy power consumption should be configured as close as possible to the power distribution room and the main control room, so as to save the cable and reduce abrasion.

3. The main control room shall have two floors. The lower level is for machine repair while the upper for monitoring real-time operation of the machines in the stone crusher plant.

4. Primary crushing is the main process for stone crusher plant. It is strongly recommended to select the primary crusher according to the properties (hardness, size and moisture etc.) of processed stone, the expected capacity and the type of finished products.

5. If the raw materials contain much dirt and impurities, a soil-off feeder can be used to pre-screen them. It helps improve the crushing efficiency in the later period and reduce clogging.

6. In order to ensure the continuity of the stone crusher plant, it is recommended to build two transfer silos ahead of and behind the secondary crushing process. In this way, the maintenance of the equipment in the previous process will not affect the subsequent process.

7. It is recommended that the processing capacity of the vibrating screen is slightly larger than that of the crusher. It will not only improve the screening efficiency, but also reduce the load on the shaker and prolong its service life.

8. In addition to polluting the environment, the traditional scattered product storage model is not conducive to sales. Therefore, it is recommended to design a unified and standardized finished product silo for the stone crusher plant.

9. In order to meet the requirements of environmental protection, remember to install dust removal equipment at the main dust points, design a closed production process and carry out sprinkling within stone crusher plant on a regular basis.

The above 9 tips apply to most stone crusher plants. If you have special requirements, it is necessary to communicate with the professional manufacturers. Zhongyu Dingli offers tailored design for 50-3000tph stone crusher plants, please do not hesitate to contact us if you need any consultation.
